LZZBJ9-10A, C Current Transformer
Product Functions
The LZZBJ9-10A/C series serves as a critical sensing and isolation component in 10kV power distribution networks. Its primary function is to accurately step down high primary currents (up to 1500A) to standardized, safe secondary levels (1A or 5A) for monitoring and control. Depending on the selected model variant (A or C), it provides precise signals for energy metering and billing (0.2S class) and/or general measurement (0.5 class), while simultaneously delivering stable outputs for circuit protection (10P class) via integrated dual-winding or triple-winding designs.
Applicable Environment
This product line is engineered for indoor installations within controlled environments. It is ideally suited for integration into 10kV metal-clad switchgear, ring main units (RMUs), compact substations, and indoor distribution panels. Typical applications include industrial plant electrical rooms, commercial building power distribution centers, data center power infrastructure, and renewable energy grid-connection points where equipment is protected from direct weather exposure. It is a core component for safe and efficient power management in medium-voltage indoor switchgear.
Product Highlights
◆High Flexibility & Versatility: Offers multiple standard accuracy combinations (0.5/10P, 0.2S/10P, 0.2S/0.5/10P) in the A and C variants to meet diverse application needs from pure protection to combined metering, measurement, and protection within a single compact unit.
◆Broad Current Range: Covers an extensive primary current rating from 10A to 1500A with a choice of 1A or 5A secondary output, providing exceptional application adaptability for various load profiles and system designs.
◆Optimized Performance & Compliance: Designed with matched rated capacities (10/15VA or 10/15/15VA) corresponding to each accuracy class, ensuring optimal performance. Manufactured in strict accordance with the international benchmark GB/T 20840.2-2014, guaranteeing reliability and safety.
◆Robust Insulation Design: Features a solid insulation level of 12/42/75kV, ensuring long-term dielectric strength, operational safety, and reliability under standard and transient overvoltage conditions in 10kV systems.
